Ultrapure water is very important in many industrial applications. RO membrane filmtec are treated as extremely high filter applications in industrial field.
Application field ranges from pharmaceutical,electronics and semiconductor to power industry.
CPA lines of spiral-wound RO membranes are available in different sizes and has wonderful performance with the highest salt rejection rates for brackish water applications.
High throughput, efficiency and cost-effectiveness make CPA membranes the best high-rejection brackish water RO membranes .
CPA3(only in 8040) with 99.7 percent rejection which is an upgrade to the CPA2 with 10 percent more membrane area (around 400 square feet). This resulted in reduced capital costs by requiring fewer pressure vessels and less space.
Performance:
6.5 - 7.0 pH Range
Product Description:
Configuration: Spiral Wound
Feed Spacer: 34 mil (0.86 mm)
Packaging: All ro membrane filmtec are supplied with a brine seal, interconnector, and O{{0}}rings. Elements are enclosed in a sealed polyethylene bag and then packaged in a cardboard box. Wet membranes include a solution containing less than 1.0 percent sodium meta-bisulfite.
| A. Inches(mm) | B.Inches(mm) | C,Inches(mm) |
| 40.0 (1016) | 7.89(200) | 1.125(28.6) |
Values listed are indicative, not specified. For more detailed specifications, see our Technical Service Bulletin documents .
Maximum Applied Pressure: 600 psig (4.14 MPa)
Maximum Chlorine Concentration: < 0.1="">
Maximum Operating Temperature: 113 degree F (45 degree )
pH Range, Continuous (Cleaning): 2-10.8 (1-12.5)
Maximum Feedwater Turbidity: 1.0 NTU
Maximum Feedwater SDI (15 mins): 5.0
Maximum Feed Flow: 85 gpm (19.3 m3/h)
Minimum Brine Flow: 12 gpm (2.7 m3/h)Maximum Pressure Drop for Each Element: 15 psi (0.10 MPa)
